A gantry Type Band Sawing Machine For Channel Steel is a gantry-type band saw machine specially designed for channel steel cutting. With its advanced technology and stable performance, it has become an ideal choice for cutting large materials.
This gantry-style band saw is designed to cut specially shaped materials such as channel steel efficiently and accurately. The optimization of its structure and functions makes it an industry in the field of channel steel cutting.
The equipment uses a hydraulic system to tension the saw blade to ensure the stability of the saw blade during the cutting process. This advanced hydraulic technology ensures the accuracy and efficiency of sawing and is suitable for channel steel materials that require high cutting quality.
The feeding method adopts hydraulic worktable movement, which improves the material feeding efficiency. The operator can flexibly move the workbench through simple hydraulic control to adapt to the cutting needs of channel steel of different sizes.
The guide system uses linear guide rails with imported technology to ensure precise guidance during the cutting process. This advanced guiding technology provides reliable support for special-shaped materials such as channel steel, ensuring cutting accuracy.
The main transmission system adopts German technology spiral bevel gear reducer to provide strong power support. This high-quality transmission system ensures the reliability and durability of the equipment and is suitable for high-intensity cutting of large channel steel.
The sawing feed system adopts a gantry-type structure with guide rails. The saw beam is hydraulically controlled to rise and fall along the guide rails through dual oil cylinders to achieve step-less speed regulation of the feed. This design makes the cutting process more flexible, and the cutting speed can be adjusted according to the cutting needs of different channel steels.
The structure of the equipment is stable, and the gantry design ensures high stability in channel steel cutting. Narrow saw kerf and precise cutting ensure the quality of cutting and meet the demand for high-precision cutting of channel steel materials.
The linear speed of the saw blade can be infinitely adjusted and adopts frequency converter technology to achieve energy-saving and efficient cutting. This not only helps reduce energy consumption but also improves the operating efficiency of the equipment.
Gantry Type Band Sawing Machine For Channel Steel is an advanced equipment that combines hydraulic pressure, imported technology, and German technology, providing efficient, stable and precise cutting solutions for special-shaped materials such as channel steel. Its stable structure, precision sawing technology and advanced hydraulic system make it stand out in the field of channel steel cutting, providing efficient help for your production.
|
Model |
GB4265X |
|
Cutting Range(mm) |
Φ600×700×600 |
|
Saw Blade Size(mm) |
7140×54×1.6 |
|
Feeding Speed |
Stepless Speed Control |
|
Saw Blade Speed(m/min) |
25.45.65 |
|
Total Power(kw) |
10.59 |
|
Fastening Mode |
Hydraulic |
|
Overall Size(mm) |
3400×1500×2400 |
